Error adding container to network "ovn-kubernetes"

I've recently noticed problems with my openshift cluster. I can't even make a simple pod like this.

cat <<EOF | oc apply -f -
apiVersion: v1
kind: Pod
metadata:
  name: testpod
spec:
  containers:
  - name: testcontainer
    image: centos/tools
    imagePullPolicy: IfNotPresent
    command: [ "/bin/bash", "-c", "--" ]
    args: [ "while true; do sleep 1000; done;" ]
EOF
Enter fullscreen mode Exit fullscreen mode

Captain Penguine

When I describe the pod I was seeing following error message.


Warning FailedCreatePodSandBox 16s kubelet Failed to create pod sandbox: rpc error: code = Unknown desc = failed to create pod network sandbox k8s_testpod_openshift-ovn-kubernetes_e9d3a164-5126-424f-8783-7eda60f82db3_0(938e2842599776af1a1efae17043e261c4278219db7a2a2cd049d2ac3d6014ec): error adding pod openshift-ovn-kubernetes_testpod to CNI network "multus-cni-network": [openshift-ovn-kubernetes/testpod:ovn-kubernetes]: error adding container to network "ovn-kubernetes": CNI request failed with status 400: '[openshift-ovn-kubernetes/testpod 938e2842599776af1a1efae17043e261c4278219db7a2a2cd049d2ac3d6014ec] [openshift-ovn-kubernetes/testpod 938e2842599776af1a1efae17043e261c4278219db7a2a2cd049d2ac3d6014ec] failed to get pod annotation: timed out waiting for annotations

If you look at the log closely you will notice following error log.

error adding container to network "ovn-kubernetes"
Enter fullscreen mode Exit fullscreen mode

It appears that ovn-kubernetes is unable to provide this pod an IP address.

The next obvious step is to determine whether the ovn-kubernetes component is operational or not. The component is running on openshift-ovn-kubernetes namespace.

oc get pods -n openshift-ovn-kubernetes | grep ovnkube-master
Enter fullscreen mode Exit fullscreen mode

Output:

NAME                   READY   STATUS              RESTARTS   AGE
ovnkube-master-pbg8h   6/6     Running             40         111d
ovnkube-master-rz6dg   6/6     Running         46         111d
ovnkube-master-vjvk8   6/6     Running             93         111d
Enter fullscreen mode Exit fullscreen mode

Check logical_switch_port in nbdb database container

There are a lot of reboots going right now. You may do the following to check for "failed" pod entries in nbdb containers:

oc exec -n openshift-ovn-kubernetes ovnkube-master-pbg8h -c nbdb -- ovn-nbctl --no-leader-only list logical_switch_port openshift-monitoring_alertmanager-main-1
Enter fullscreen mode Exit fullscreen mode

Output:

_uuid               : 0f1a1aa2-8403-42d2-b366-3ec17184db1f
addresses           : ["0a:45:0a:83:04:1a 10.131.4.27"]
dhcpv4_options      : []
dhcpv6_options      : []
dynamic_addresses   : []
enabled             : []
external_ids        : {namespace=openshift-monitoring, pod="true"}
ha_chassis_group    : []
name                : openshift-monitoring_alertmanager-main-1
options             : {requested-chassis=worker-6.core-pre.goglides.dev}
parent_name         : []
port_security       : ["0a:45:0a:83:04:1a 10.131.4.27"]
tag                 : []
tag_request         : []
type                : ""
up                  : true
Enter fullscreen mode Exit fullscreen mode

The result indicates that the component is up. I have no idea what is happening. I did the following to restart every pod from ovnkube-master.

oc delete pods -l ovn-db-pod=true
Enter fullscreen mode Exit fullscreen mode

After sometimes all ovnkube-master pods are up and running,

oc get pods -l ovn-db-pod=true
NAME                   READY   STATUS    RESTARTS   AGE
ovnkube-master-djw2j   6/6     Running   0          16m
ovnkube-master-fc87t   6/6     Running   0          10m
ovnkube-master-jc2ln   6/6     Running   0          13m
Enter fullscreen mode Exit fullscreen mode

Somehow this also fixes the issue. Now my testpod is running.

oc get pods testpod -o wide
NAME      READY   STATUS    RESTARTS   AGE   IP            NODE                           NOMINATED NODE   READINESS GATES
testpod   1/1     Running   0          42m   10.129.4.16   worker-8.core-pre.goglides.dev   <none>           <none>
Enter fullscreen mode Exit fullscreen mode

Original solution posted here in redhat forum.
